Aleph HA-125D Photoelectric Dual Beam Detectors

<< Previous in Security Next in Security >>
Aleph HA-125D Photoelectric Dual Beam Detectors 125ft
Aleph HA-125D Photoelectric Dual Beam Detectors 125ft
Price: $187.49
In Stock: 10
Item Number: HA-125D
Manufacturer: AI NEXT, LLC
Manufacturer Part No: HA-125D

Quantity Discounts

QuantityAmount
20 to 59$178.11
60 to 99$168.74
100 to 9999$149.99

Aleph Unicorn HA-125D Photoelectric Dual Beam Detectors

***Discontinued***, Photoelectric Detectors provides the most advanced features in a very attractive, compact weather resistant design. Included in our "HA" series are Dual Beam - Pulse Infrared, Sealed Optics, Variable Beam Interuption Time, Indoor/Outdoor Use, Metered Voltage Outputs, and Simple-To_Use Viewfinder for Easy Alignment.

Photo Beams (Invisible Fence) can be used for defense perimeter security, entry alert or as a trigger for an open/close gate system. Solutions for many applications, which require both beams to be broken in order to trigger (NO/NC) an event.

  • Indoor, Outdoor Use
  • Dual Photo Beam - Pulsed Infrared, Sealed Optics
  • Alarm Trips Only When Both Beams are Interrupted
  • NO = Normally Open Loop
  • NC = Normally Closed Loop
  • Dry Contact Relay Output
  • No Heater Required
  • Variable Beam Interruption Time
    • 50 msec to 500 msec
  • Operational -13 F to 131 F
  • Kit Includes Wall/Pole Mounting Hardware
  • Detection Distance
    • 40 meters Outdoors (125 ft)
  • Color:
    • UPC:  6938942620229 (Black)   P/N:  HA-125D



Specifications

SpecificationsHA-125D
Coverage, Outdoor 40 m. / 125 ft.
Coverage, Indoor 80 m. / 250 ft.
Sensing Type Pulsed Active Infrared
Alarm Output Form A or Form B / NC/NO (selectable), 24 VDC / 1 A
Alarm Duration 2 sec. ±1 sec.
View Adjustment Horizontal 180° (±90°), Vertical 10° (±5°)
Supply Voltage 11 to 26 VDC
LED Indication Power On: Green; Standby/Power On: Green; Alarm: Red
Current Draw 10 mA / 27 mA
Application Indoor / Outdoor
Temperature Range -25° C to 55° C (-13° F to 131° F)
Mounting Type Wall or pole mount
Construction Black polycarbonate
Weight Transmitter: 340 g (0.75 lb.); Receiver 350 g (0.8 lb)
